portable ultrasound pulse heating soft tissue injury cure machine

ULTRASONIC ENERGY METER GY-CS01

Therapeutic ultrasound is one of the most common treatments used in the management of soft tissue lesions.

It is over 70 years since the interactions between high (‘ultra’)‐frequency sound waves and living tissue were initially studied and the use of such energy as a form of therapy was first suggested . Ultrasound has since been used to treat a wide variety of disorders, from skin wounds to malignant tumours . It has become one of the most commonly used treatments in the management of soft tissue injuries, and it has been estimated that over a million NHS treatments annually involve its use.

Therapeutic ultrasound has a frequency range of 0.75–3 MHz, with most machines set at a frequency of 1 or 3 MHz. Low‐frequency ultrasound waves have greater depth of penetration but are less focused. Ultrasound at a frequency of 1 MHz is absorbed primarily by tissues at a depth of 3–5 cm and is therefore recommended for deeper injuries and in patients with more subcutaneous fat. A frequency of 3 MHz is recommended for more superficial lesions at depths of l–2 cm.

Recognized by the Intemational Health Organization as the "green health channel" of the century.

Ultrasound therapy has been in the western developed countries for about 80 years. it belongs to the national basic treatment program,which is applied to pain department and rehabilitation and physiotherapy department.

Introduction to ultrasound

Scientists refer to the number of vibrations per second as the frequency of the sound, and its unit is Hertz (Hz). The frequency of sound waves that we can hear in human ears is 20 Hz to 20,000 Hz. When the vibration frequency of the sound wave is less than 20 Hz or greater than 20,000 Hz, we will not hear it. Therefore, we call sound waves with frequencies above 20,000 Hz "ultrasonics". The ultrasonic frequency commonly used for medical diagnosis is 1 megahertz to 10 megahertz which can be used for ranging, industrial flaw detection, cleaning, welding, drilling, crushing, sterilization and so on.

The safety of ultrasound

The use of ultrasonic waves in the human tissue has good penetrability, directionality and energy stacking characteristi.cs, the use of ultrasonic warming effect, mechanical effects and physical and chemical effects, massage loosening adhesion and health effects.

Principle of Ultrasonic Energy Meter

The frequency of the ultrasonic energy meter is 1 megahertz (1 million Hz / s), the direction being accurate, and the penetration being strong. Through the three major effects of sound waves (mechanical, warm, physical and chemical effects) on various parts of the human body, to achieve the role of massage relaxation.

Product function

1. Mechanical effect - high frequency vibration: pain relief, soften tissue, enhance penetration, improve metabolism, promote blood circulation, stimulate nerve system and cell.

2. Warming effects: deep heating,penetrate below the muscle.It’s applied to chronic soft tissue pain, arthritis, rheumatism.

3. Physical and chemical effects - cavitation: based on the mechanical and heating function, it will trigger physical therapy.

a) Hydrogen ion concentration changes:reduce inflammation.

b) Effects on enzyme activity:affecting the activity of many enzymes.

c) many highly active free radicals can be formed in the tissue. They can accelerate the redox process in the tissue and accelerate the growth process.

Feature

The appearance is simple and generous, the LCD screen is used, and the operation is easy to understand and the intensity is adjusted by 5 gears (0.8, 1.2, 1.6, 2.0, 2.5), the time is 5-30min, and the interval is 5 minutes.

Humanized Safety Design

1. Anti-overheating intelligent temperature control protection device, five-speed being adjustable (with thermistor induction temperature, the maximum temperature does not exceed 50 °C), safer and more secure.

2. Anti-overcurrent protection device effectively solves the problem that the current is too high and the current caused by the contact difference is high to cause the instrument being damaged.

Atomization test and penetration test: the test effect is intuitive through visual sense to feel ultrasonic shock.

Product application

The shoulder, neck, back,hands,waist,knee and joints can be experienced.

1. Apply gel to the probe or experience area before use.

2. Mobility method : The ultrasound head is placed at the pain point, centered on the pain point, and moved circumferentially or reciprocally (3-2 cm/s).

3. Fixed method: According to the experience of the experiencer, stay in a place for 5-10 seconds, then move in a circular motion for 10 seconds, and repeat the crossover.

Usage times: 1-2 times a day, no experience for 10 minutes each time, 7 days a period.

Level Selection

1. Face, neck, hands and other muscles and thin parts of the fat, select the "low" level key.

2. Arm, sole, calf, back and other parts, select the "middle" level key.

3. Thicker parts of the subcutaneous tissue such as the waist, abdomen, thighs and buttocks, select the “high” level key.

The above levels are recommended for reference only. When using , the ultrasonic levels can be adjusted according to the actual situation, and the principle of adjustment from low to high-level is followed, step by step.
